TYPHON THUNDERDUMP 180 – KONSTRUCTZ Series view 1
1/5
KONSTRUCTZ FleetDumpersSKU: THUNDERDUMP-180In Stock • Ships in 1-2 Days

TYPHON THUNDERDUMP 180 – KONSTRUCTZ Series

Heavy-Duty 6-Wheel Articulated Site Hauler with 2,866 lb Payload

Max Load Capacity2,866 lbs1,300 kg Payload
Operating Weight1,058 lbs480 kg Tare
Engine ModelHonda GX39011 HP OHV Gas
Tires / Drive6 WheelsAll-Terrain Traction
Cargo Box55.1 × 31.5 in23.6 in Deep
Max Gradeability26°High Incline Power
Commercial ProcurementRequest Commercial Quote
Includes Standard Bucket & Hydraulic Thumb
Request Commercial QuoteFull Spec Sheet
Need quick jobsite sizing, freight quote, or wholesale terms?Call (213) 214-2203
1-Year Commercial Warranty
Nationwide Flatbed Delivery
EPA Tier 4 Final Engine
In-Stock Parts & Tech Support
Engineering Architecture

Commercial Overview: ThunderDump 180

The TYPHON THUNDERDUMP 180 is the heavy-hauler in the KONSTRUCTZ dumper lineup. Engineered with a robust 6-wheel articulated chassis, this machine carries up to 2,866 lbs (1,300 kg) of bulk material across rugged jobsites, construction projects, farm lanes, and large properties.

Equipped with the trusted Honda GX390 commercial OHV gasoline engine delivering 11 HP at 3,600 RPM, the THUNDERDUMP 180 provides continuous torque to all six heavy-tread flotation wheels. This ensures dependable forward drive through loose gravel, sand, mud, and over 26-degree slopes without slipping.

The heavy-gauge steel cargo box measures 55.1 × 31.5 × 23.6 inches (1,400 × 800 × 600 mm), providing massive volumetric capacity for soil, gravel, brick, firewood, and demolition debris. When reaching the dump zone, a high-pressure hydraulic ram elevates the bed for quick, effortless unloading.

With an overall width of 49.2 inches (1,250 mm) and an empty weight of only 1,058 lbs (480 kg), the THUNDERDUMP 180 moves 15 times the payload of a traditional manual wheelbarrow while maintaining low maintenance overhead and simple small-engine reliability.

Competitive Advantage

Why Contractors Choose the ThunderDump 180

Three critical engineering decisions that translate into lower operating costs and higher jobsite throughput.

2,866 lb Maximum Payload

Engineering Feature
Heavy Reinforced Steel Cargo Box
Technical Reason
Heavy-duty chassis geometry with 6 load-bearing wheels distributes near 1.5-ton loads safely.
Practical Contractor Benefit
Haul massive volumes of wet soil, concrete chunks, and gravel in a single trip, cutting transit labor in half.

6-Wheel All-Terrain Traction

Engineering Feature
Six Heavy-Tread Flotation Tires
Technical Reason
Triple-axle configuration maintains constant ground contact over ruts, rocks, and mud.
Practical Contractor Benefit
Traverse rough, uneven construction ground and climb steep 26-degree slopes without getting stuck.

Honda GX390 Commercial Engine

Engineering Feature
11 HP OHV 4-Stroke Gasoline Powertrain
Technical Reason
Industrial overhead valve architecture with cast-iron cylinder sleeve and mechanical governor.
Practical Contractor Benefit
Dependable pull and electric starting, standard pump gas operation, and universal parts availability.

Fast Hydraulic Dump Cylinder

Engineering Feature
Hydraulic Bed Tipping Mechanism
Technical Reason
High-pressure hydraulic cylinder rapidly tilts the cargo box to a steep angle for fast material release.
Practical Contractor Benefit
Discharge 1.4 tons of heavy aggregate in seconds without manual physical strain.
Technical Data Sheets

TYPHON THUNDERDUMP 180 – KONSTRUCTZ Series Full Specifications

Dual-unit specifications (US Standard primary, Metric secondary) verified for commercial procurement and jobsite validation.

Engine & Drive System

Engine ModelHonda GX390 OHV (Gasoline)
Engine Power11 HP @ 3,600 RPM
Fuel Type87 AKI / 92# Gasoline
Fuel Tank Capacity1.59 gal (6.0 L)
Tires6 All-Terrain Wheels
Max Gradeability26°

Payload & Dimensions

Maximum Load Capacity2,866 lbs (1,300 kg)
Operating Weight (Tare)1,058 lbs (480 kg)
Chassis Width49.2 in (1,250 mm)
Cargo Box Length55.1 in (1,400 mm)
Cargo Box Width31.5 in (800 mm)
Cargo Box Depth23.6 in (600 mm)
Dumping MethodHydraulic Dump
Logistics & Tooling

Jobsite Footprint & Compatibility

Clear dimension clearances, trailer towing parameters, and auxiliary attachment options.

Dimensions & Access Clearance

Overall width is 49.2 in (1,250 mm); cargo box is 55.1 × 31.5 × 23.6 in; empty tare weight is 1,058 lbs.

Trailer Towing & Hauling

Tows easily in a standard utility trailer or pickup truck bed; tare weight of only 1,058 lbs.

Practical Workloads

Where the ThunderDump 180 Excels

Common jobsite tasks and industry applications where this machine delivers maximum efficiency.

01

Bulk Aggregate & Gravel Distribution

Move tons of crushed stone, river rock, and sand from roadside delivery piles to remote project sites.

02

Agricultural Farm & Estate Maintenance

Transport feed bags, firewood, fencing supplies, and livestock bedding across large acreage.

03

Construction Demolition Hauling

Transport heavy broken concrete, brick rubble, and plaster scraps across commercial sites.

04

Parks, Golf Courses & Orchard Care

Move pruning branches, topsoil, and fertilizers without tearing grass on manicured grounds.

Ideal Fleets

Built for These Trades & Operators

Landscape & Hardscape Contractors

Teams needing high payload capacity across open commercial and residential sites.

Farm & Ranch Managers

Property managers moving feed, firewood, manure, and fencing materials over rolling acreage.

General Building Contractors

Builders moving bulk supplies and debris without commercial heavy equipment transport requirements.

Model FAQs

TYPHON THUNDERDUMP 180 – KONSTRUCTZ Series Technical Inquiries

Detailed answers on hydraulics, fluid maintenance, transport, and operation.

How much material can the THUNDERDUMP 180 carry?
The THUNDERDUMP 180 carries up to 2,866 lbs (1,300 kg) of soil, stone, debris, or materials in its 55-inch steel cargo box.
How does the 6-wheel drive handle mud and hills?
With six all-terrain tires distributing the load, it easily climbs 26-degree slopes and navigates loose gravel and wet turf with high stability.
How does the dumping mechanism work?
It features a high-pressure hydraulic cylinder powered by the Honda engine that tips the cargo bed with a fingertip control lever.
What engine is in the THUNDERDUMP 180?
It is powered by an authentic Honda GX390 commercial 4-stroke gasoline engine producing 11 HP.
What is the chassis width of the THUNDERDUMP 180?
The machine measures 49.2 inches (1,250 mm) wide, designed for open sites, farm gates, and double commercial gates.
